38mm Planetary Gearmotors

38mm Planetary Gearmotor

Choose AmpFlow compact 38 mm planetary gearmotors with integrated encoders when extreme precision, integrated feedback, and moderate torque are required. Our planetary gearheads deliver low backlash, high repeatability, and smooth torque transmission across a wide range of reduction ratios. These motors can be used with voltages ranging from 12V to 36V. Available reduction ratios range from 1:5 to 1:100.

Type	38mm Planetary Motor with Encoder
Voltage Range	12 to 48 Volts
Model	D38-24-PR5	D38-24-PR27	D38-24-PR100
Nominal Voltage	24V¹	24V¹	24V¹
Nominal Power	20W	20W	20W
Reduction Ratio	1:5	1:27	1:100
Backlash (Max)	2°	2°	2°
Continuous Torque (Nm)	0.09	0.4	1.25
No-Load RPM	1150	220	60
Length (mm)	103	112	121
Weight (lbs)	0.9	1.0	1.2
Price	$69	$79	$84
Pictures
Drawings
Order

¹ The above specifications are for the motor's nominal voltage. The motors can also be used at lower or higher voltages. The RPM is proportional to the voltage, so running at half the nominal voltage will result in half the speed, and twice the voltage will double the speed. The maximum achievable torque is also proportional to the voltage. Shorter duty-cycles are recommended for higher voltages to allow the motors time to cool.

Encoder

The 38 mm planetary gearmotors are supplied with a magnetic encoder. The encoder is mounted on the back of the motor and includes a 10-inch cable. It has a resolution of 13 PPR.

Here is the wiring chart:

Red: +5VDC
Black: Ground
Yellow: Channel A
White: Channel B

Here is the Datasheet.

Warranty

The gearmotors are warranted to be free from manufacturing defects and fully operational when you receive them. AmpFlow gives no other warranty, either expressed or implied. Warranties are not transferable. In no event shall AmpFlow's liability exceed the buyer's purchase price, nor shall AmpFlow be liable for any indirect or consequential damages.
